Features
- Double sealed ball bearings
- Automatic reset thermal protector
- Quick-connect design
- Reversible
General Specifications
| UPC: | 786674074928 | Weight: | 46.00 LB |
| Packaged Length: | 19 IN | Packaged Width: | 8 IN |
| Packaged Height: | 8 IN |
Nameplate Specifications
| Output HP: | 2.0 Hp | Output KW: | 1.5 kW |
| Frequency: | 60 Hz | Voltage: | 208-230/460 V |
| Current: | 6.3-6.2/3.1 A | Speed: | 1140 rpm |
| Service Factor: | 1 | Phase: | 3 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | 56Y | Enclosure: | Totally Enclosed Air Over |
| Thermal Protection: | Thermally Protected | Ambient Temperature: | 70 °C |
| UL: | Recognized | CSA: | Y |
| CE: | N |
Technical Specifications
| Electrical Type: | Three Phase | Starting Method: | Across The Line |
| Poles: | 6 | Rotation: | Reversible |
| Mounting: | Round | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | Keyed | Overall Length: | 16.70 in |
| Frame Length: | 10.25 in | Shaft Diameter: | 0.625 in |
| Shaft Extension: | 3.44 in |
Speed & Load Characteristics
