Specifications
| Brand | KBC Bearings |
|---|---|
| Manufacturer Part Number | 6007DDC3G14 |
| Group | Deep Groove Ball Bearings |
| Type | Contact Sealed (2RS) |
| Bore / Inside Diameter (d) | 35 mm |
| Housing / Outside Diameter (D) | 62 mm |
| Width (B) | 14 mm |
| Minimum Radius (r) | mm |
| Operating Temperature | -30 to 110°C |
| Cage Type | Pressed Steel Cage |
| Configuration | Single-row |
| Tolerances | JIS B 1514 |
| Allowable Misalignment | .002 3 - .003 4 rad ( 8’ - 12’ ) |
| Basic Load Rating | Cr 13.2 kN C0r 8.25 kN |
| Fatigue Load Limit (Cu) | kN |
| Factor (f0) | |
| Limiting Speeds (Grease Lubrication) | min-1 |
| Shaft Shoulder Mounting Dimension (da) | mm Minimum mm Maximum |
| Housing Shoulder Mounting Dimension (Da) | mm Maximum |
| Shoulder Radius (ra) | mm Maximum |
| Mass | kg lbs |
| UPC | |
| Country of Manufacture | Japan |
