EM31115 Baldor 1HP Electric Motor, 3450RPM

$590.49 USD

Shipping calculated at checkout

Baldor Electric Company SKU: EM31115 Barcode: 781568732823

30 Day
Return Policy

Ships Fast
in 24 hours

ODP, 56 Frame, 230/460VAC 60Hz 3-Phase, 3420M, Foot Mounted, Rolled Steel, 5/8" Keyed Shaft

Description Product Specs Manufacturer

Specifications

Specs

Catalog NumberEM31115
EnclosureODP
Frame56
Frame MaterialSteel
Frequency60.00 Hz
Output @ Frequency1.000 HP @ 60 HZ
Phase3
Synchronous Speed @ Frequency3600 RPM @ 60 HZ
Voltage @ Frequency230.0 V @ 60 HZ
460.0 V @ 60 HZ
XP Class and GroupNone
XP DivisionNot Applicable
Agency ApprovalsC UR US ENERGY
Ambient Temperature40 °C
Auxillary BoxNo Auxillary Box
Auxillary Box Lead TerminationNone
Base IndicatorRigid
Bearing Grease TypePolyrex EM (-20F +300F)
BlowerNone
Current @ Voltage1.600 A @ 460.0 V
3.200 A @ 230.0 V
3.500 A @ 208.0 V
Design CodeB
Drip CoverNo Drip Cover
Duty RatingCONT
Efficiency @ 100% Load77.0 %
Electrically Isolated BearingNot Electrically Isolated
Feedback DeviceNO FEEDBACK
High Voltage Full Load Amps1.6 a
Front Face CodeStandard
Front Shaft IndicatorNone
Heater IndicatorNo Heater
Insulation ClassF
Inverter CodeNot Inverter
KVA CodeL
Lifting LugsNo Lifting Lugs
Locked Bearing IndicatorNo Locked Bearing
Motor Lead ExitKo Box
Motor Lead TerminationFlying Leads
Motor Lead Quantity/Wire Size9 @ 18 AWG
Motor Type3420M
Mounting ArrangementF1
Number of Poles2
Overall Length10.88 IN
Power Factor82
Product FamilyGeneral Purpose
Pulley End Bearing TypeBall
Pulley Face CodeStandard
Pulley Shaft IndicatorStandard
Rodent ScreenNone
RoHS StatusROHS COMPLIANT
Service Factor1.25
Shaft Diameter0.625 IN
Shaft Extension LocationPulley End
Shaft Ground IndicatorNo Shaft Grounding
Shaft RotationReversible
Shaft Slinger IndicatorNo Slinger
Speed3450 rpm
Speed CodeSingle Speed
Motor StandardsNEMA
Starting MethodDirect on line
Thermal Device - BearingNone
Thermal Device - WindingNone
Vibration Sensor IndicatorNo Vibration Sensor
Winding Thermal 1None
Winding Thermal 2None

Applications

  • Fans
  • Pumps
  • Blowers
  • Conveyors
  • Compressors
  • Industrial machines
  • Other general purpose applications

Features

  • Suitable for inverter use per NEMA MG1 Part 31.4.4.2
  • Designed for longevity with a 3 year warranty on premium efficient Super-E® motors
  • Optimized airflow design providing higher horsepower in a smaller package

Nameplate

Nameplate

CAT.NO. EM31115
SPEC. 34B061-3226G1
HP 1
VOLTS 230/460
AMPS 3.2/1.6
RPM 3450
FRAME 56 HZ 60 PH 3
SF 1.25 CODE L DES B CLASS F
F.L. AVG. EFF. 77 PF 82
RATING 40C AMB-CONT
CC USABLE AT 208V 3.5
DE 6203 ODE 6203
ENCL ODP SN
USABLE AT 50HZ 1HP 190/380V 3.4/1.7A SF1.0
NP3155LUA

Performance

Performance

Performance at 460 V, 60 Hz, 1 hp

Typical performance; not guaranteed values.

General Characteristics

Full Load Torque0 LB-FT
No-Load Current0 A
Line-Line Res. @ 25° C12.852 Ohms A Ph / 0 Ohms B Ph
Temp. Rise @ Rated Load19° C
Temp. Rise @ S.F. Load23° C
Start ConfigurationDOL
Break-Down Torque7.7 LB-FT
Pull-Up Torque5.67 LB-FT
Locked-Rotor Torque7.34 LB-FT
Starting Current14.7 A

Load Characteristics

Rated Load 0% 25% 50% 75% 100% 125% 150% S.F.
Power Factor 17.0 42.0 60.0 73.0 80.0 85.0 88.0 85.0
Efficiency 0.0 61.1 74.0 78.8 80.8 81.4 81.0 81.4
Speed (RPM) 3,590 3,568 3,546 3,520 3,494 3,464 3,431 3,464
Line Amps 0.86 0.94 1.07 1.24 1.46 1.70 2.00 1.70

Performance Curves

Performance at 230 V, 60 Hz, 1 hp

Typical performance; not guaranteed values.

General Characteristics

Full Load Torque0 LB-FT
No-Load Current0 A
Line-Line Res. @ 25° C3.213 Ohms A Ph / 0 Ohms B Ph
Temp. Rise @ Rated Load19° C
Temp. Rise @ S.F. Load23° C
Start ConfigurationDOL
Break-Down Torque7.7 LB-FT
Pull-Up Torque5.67 LB-FT
Locked-Rotor Torque7.34 LB-FT
Starting Current29.4 A

Load Characteristics

Rated Load 0% 25% 50% 75% 100% 125% 150% S.F.
Power Factor 17.0 42.0 60.0 73.0 80.0 85.0 88.0 85.0
Efficiency 0.0 61.1 74.0 78.8 80.8 81.4 81.0 81.4
Speed (RPM) 3,590 3,568 3,546 3,520 3,494 3,464 3,431 3,464
Line Amps 1.72 1.87 2.14 2.48 2.92 3.40 4.00 3.40

Performance Curves

  • Electric Motor
  • 56
  • ODP
  • 3-Phase
  • 1HP
  • 3450RPM

Baldor Electric Company
