| range | PowerPact |
|---|---|
| product name | PowerPact Q |
| Product or Component Type | Circuit breaker |
| Device Application | Distribution |
| Line Rated Current | 200 A |
|---|---|
| Number of Poles | 3P |
| Control Type | Operating handle |
| breaking capacity code | D |
| breaking capacity | 25 kA 120/208 V AC 50/60 Hz UL 25 kA 240 V AC 50/60 Hz UL |
| [Ue] rated operational voltage | 240 V AC 50/60 Hz UL |
| Network Frequency | 50/60 Hz |
| [Uimp] rated impulse withstand voltage | 8 kV UL |
| trip unit technology | Thermal-magnetic |
| magnetic tripping current | 2400 A |
| magnetic hold current | 1200 A |
| continuous current rating | 80 % |
| utilisation category | Category A |
| Mechanical durability | 1000 cycles loaded 5000 cycles no load |
| local signalling | 1 trip indicator green) |
| mounting mode | Unit mount lug) |
| Mounting Support | Lug |
| electrical connection | Terminal nut line Lugs load |
| tightening torque | 247.82 lbf.in (28 N.m) 0.04…0.23 in² (25…150 mm²) (AWG 4...300 kcmil) |
| Power wire stripping length | 0.87 in (22 mm) |
| Height | 6.47 in (164.34 mm) |
| Width | 4.5 in (114.30 mm) |
| Depth | 3.93 in (99.82 mm) |
| standards | UL CSA NEMA NOM-003-SCFI-2000 |
|---|---|
| product certifications | UL CSA NOM |
| Ambient Air Temperature for Operation | 104…158 °F (40…70 °C) |
| Category | 00024-Q2 & QE METERING BREAKERS |
|---|---|
| Discount Schedule | DE2A |
| GTIN | 785901671398 |
| Nbr. of units in pkg. | 1 |
| Package weight(Lbs) | 4.56 lb(US) (2.07 kg) |
| Country of origin | MX |
