Specifications
| Standard | NEMA MG-1 |
|---|---|
| Degree of Protection | IP66 |
| Mounting | F-1 |
| Flange | C |
| Frame Material | Stainless steel |
| Frequency | 60/50 Hz |
| Output rating | 1 HP |
| Enclosure | TEFC |
| Number of poles | 2P |
|---|---|
| Motor Application | HydroDuty |
| Mounting | Footless |
| Efficiency | NEMA Premium Efficiency |
| Terminal box¹ | Left position |
| Frame | 56C |
| Voltage | 230/460 V |
| Synchronous speed | 3600/3000 rpm |
