General Specifications
- New state of the art inverter designs
- Space saving design: 2.36 in (60 mm) wide, 5.12 in (130 mm) deep, also zero-clearance mounting
- RoHS2-Compliance
- Fulfills IE2 according to new EN 50598-2
- Out of the box commissioning
- Easy commissioning with memory module
- Improved usability for easy commissioning
- Parameterization with USB module without external power supply
- Innovative interface options enable set-up times faster than ever before
- The wide-ranging modular system enables various product configurations depending on machine requirements
- Spring loaded control terminals (fixed)
- More functionalities for advanced application
- Fieldbus - CANopen/Modbus
- VFC Eco mode for more energy savings
- The Platinum e VSD is recommended in applications for pumps and fans, conveyors, formers, winders and machine tools
Set Up Methods
- Keypad - If you only need to set up a few parameters, such as acceleration time, this can be done quickly from the keypad
- Smart Keypad for use with an Android App. Enables adjustment to a simple application such as a conveyor
- Easy Starter - For use if the function is needing a potentionmeter or control, for positioning application needs to be set
Specifications
| Manufacturer | Leeson |
|---|---|
| Catalog Number | 176112.00 |
| Series | Platinum e™ VSD Series |
| Input Voltage | 200-240VAC One or 3 Phase |
| Output HP | 1/3 HP |
| Output Amps | 1.7 Amps |
| Communication Module | CANopen/Modbus |
| Dimensions | 6.1" x 2.36" x 5.12" (H x W x D) |
| Hardware | Memory Module IT-Grid Compatible Integrated EMC Filter Zero Clearance Mounting Form C Relay |
| Design | Monolithic Single Board Design |
| I/O | |
| Motor Control | V/Hz (VFC linear, square & eco) Sensorless Vector (SLVC) Sensorless PMAC |
| Enclosure | IP20 |
| Weight | 2 lbs |
| UPC | 691720100455 |
