Specifications
Shaft Size d |
N/A 1 in25.4 mm |
Bearing Type |
N/A Ball Bearing |
Bearing Number |
N/A G1100KRRB |
Dimension T |
N/A 0.736 in18.7 mm |
Series |
N/A Industrial |
Weight |
N/A 2.094 lb0.95 Kg |
Seal Type |
N/A Shroud Seal |
Housing Construction |
N/A Two-Bolt Pillow Block |
Alternate Part Name |
N/A RAK1 |
Dimensions
Base to Center Height H |
N/A 33.34 mm1.313 in |
Total Length L |
N/A 139.70 mm5.500 in |
Total Width A |
N/A 1.469 in37.3 mm |
Bolt Hole Spacing J |
N/A 104.8 mm4.126 in |
Bolt Hole Width N |
N/A 11.1 mm0.437 in |
Bolt Hole Length N1 |
N/A 20.6 mm0.811 in |
Foot Height H1 |
N/A 11.9 mm |
Total Height H2 |
N/A 69.8 mm2.748 in |
Dimension L1 |
N/A 46.6 mm1.835 in |
Inside Ring Width B |
N/A N/A |
Center of Bearing from End S |
N/A 17.4 mm0.685 in |
Dimension B1 |
N/A 1.748 in44.4 mm |
