General
| Application | For Code Conductor |
| Color Code | Red |
| Connector Type | Terminal |
| Die Index | 18;324 |
| EU RoHS Indicator | Yes |
| Feature - Barrel Style | Chamfered |
| Feature - Barrel Type | Standard |
| Material | Copper |
| Physical Attribute - Number of Holes | 2 |
| Physical Attribute - Tongue Type | Standard |
| Plated | Y |
| Plating Type | Tin - Electro Plated |
| Sub Brand | HYLUG |
| Trade Name | HYLUG™ |
| Type | Standard Barrel, Tin Plated |
| UPC | 781810505076 |
Dimensions
| Dimension - B Length fraction | 1-1/16 in |
| Dimension - B Length inch | 1.06 in |
| Dimension - Bolt Hole Size inch | 0.52 in |
| Dimension - Bolt Size fraction | 1/2 |
| Dimension - D inch | 3.01 in |
| Dimension - Hole Size mm | 14 mm |
| Dimension - L Length Overall mm | 119 mm |
| Dimension - Length Overall inch | 4.70 in |
| Dimension - N inch | 0.62 in |
| Dimension - Outside Diameter inch | 0.88 in |
| Dimension - Pad Width inch | 1.29 in |
| Dimension - Strip Length inch | 1-1/8 |
| Dimension - Stud Size inch | 1/2 |
| Dimension - Z inch | 0.64 in |
| Physical Attribute - Tongue Angle | Straight |
Electrical Ratings
| Rating - KVA | 35 kV |
| Rating - Minimum Voltage | 600 |
| Voltage - Maximum | 35000 |
Conductor Related
| Conductor - Copper DLO Size Range | N/A |
| Conductor - Copper Str Navy Size | 350 (91) Navy |
| Conductor - Copper Str Navy Size Range | 350 (91) Navy |
| Conductor - Copper Str Size | 350 kcmil |
| Conductor - Copper Str Size Range | 350 kcmil |
| Conductor - Material | Copper |
Certifications and Compliance
| Certification - CSA Approved | Yes |
| Certification - ETL | No |
| Certification - UL Recognized | No |
| Certification - cULus | No |
| Standards - RoHS Compliance Status | CM |
| UL Listed | Yes |
Logistics
| Minimum Pack Quantity | 1 |
