product or component type |
Circuit breaker
|
|
---|---|---|
range of product |
I-Line
|
|
Trip Unit Type |
Thermal-magnetic
|
|
Rating Code |
A
|
Line Rated Current |
40 A
|
|
---|---|---|
Number of Poles |
3P
|
|
Interrupt Rating |
18 kA at 480 V AC
25 kA at 240 V AC 10 kA at 250 V DC |
|
System Voltage |
250 V DC
480 V AC |
|
mounting mode |
Unit mount
|
|
electrical connection |
Lugs load
Lugs line |
|
Wire Gauge |
AWG 14...AWG 1/0 (copper) 1 cable(s)
AWG 12...AWG 1/0 (aluminium) 1 cable(s) |
|
Terminal Type |
AL100FA
|
|
magnetic hold current |
400 A
|
|
magnetic tripping current |
850 A
|
|
phase connection |
ABC
|
|
height |
6.4 in
|
|
width |
4.5 in
|
|
depth |
4.13 in
|
product certifications |
UL listed
CSA |
---|
