Specifications
| Drive Style | Slotted |
|---|---|
| Head | Round |
| Diameter-TPI | #10-32 |
| Type | Machine Screw |
| Length | 3-1/2” |
| Dimensions | ASME B18.6.3 |
| Material & Mechanical Properties | Carbon Steel per ASME B18.6.3 |
| Thread Requirements | ASME B1.1, UNC & UNF, Class 2A |
| Finish | Zinc (Fe/Zn 3AN per ASTM F1941/F1941M) |
| Head Diameter “A” | 0.359" Maximum 0.334" Minimum |
| Head Height “H” | 0.137" Maximum 0.123" Minimum |
| Slot Width “J” | 0.060" Maximum 0.050" Minimum |
| Slot Depth “T” | 0.087" Maximum 0.065" Minimum |
| Weight | 0.0234 lbs |
