130174 Barnes Submersible Pump Service Kit

$502.50

Shipping calculated at checkout

Barnes (Crane Pumps & Systems) SKU: 130174

30 Day
Return Policy

Ships Fast
in 24 hours

Sold Out

Compatible Pumps

  • 3SE3024DS - 3SE5054DS
  • 3SE3022DS - 3SE5032DS
  • 4SE2824DS - 4SE5054DS
  • 4SE2822DS - 4SE5022DS
  • Series: 3SE-DS, 1750 RPM, 60Hz
  • Series: 4SE-L, 1.9 & 2.8HP, 1150 RPM, 60Hz
  • Series: 4SE-L, 2.8, 3.7 & 5HP 1750 RPM, 60Hz
  • Series: 4SE-L, 5HP, 3450 RPM 60Hz
  • Series: 4SE-L 1.6, 2.1 & 2.8HP (1.2, 1.6 & 2.1kW) 1450 RPM, 50Hz

Contents

QTY PART# DESCRIPTION
1 017026 Square Ring
1 022873 Diaphragm
2 033730 O-Ring
1 064434 Mechanical Seal
1 062435 Mechanical Seal
1 062641 Pull Washer
6 052990 Wire Connector
1 057554 Shaft Key
1 066130 Retaining Ring
1 057882 Retaining Ring
1 059186 Shaft Key
1 038132 Jam Nut
1 053746 Ball Bearing
1 035589 Woodruff Key
6 055844 Wire Connector
1 20-24-1 Split Lock Washer
4 074449 Wire Connector
4 079318 Terminal Connector
1 070320 Impeller Washer
1 061829 "V"-Ring/td>
1 105149A Jumper Wire
1 105150 Wire Crimp Connector
1 111951 Barrel Crimp Connector
2 2-31051-224 O-Ring
2 105197 Retaining Ring
