SPV33 Ashland 1/3HP Cast Iron Sump Pump, 115VAC Single Phase-1
SPV33 Ashland 1/3HP Cast Iron Sump Pump, 115VAC Single Phase-2

SPV33 Ashland 1/3HP Cast Iron Sump Pump, 115VAC Single Phase

$237.00

Shipping calculated at checkout

Ashland Pump SKU: SPV33

30 Day
Return Policy

Ships Fast
in 24 hours

In stock!

Features

  • Heavy duty cast iron/thermoplastic construction
  • Oil-filled continuous duty PSC motor
  • Upper and lower ball bearing construction for smoother operation
  • Automatic operation

Specifications

Brand Ashland Pump
Model SPV33
Switch Type Float
HP 1/3 HP
Voltage 115VAC 60Hz Single Phase
RPM 1750 RPM
Full Load Amps 5 Amps
Cord Type SJTW 18/3C
Cord Power Size 16AWG/3C
Discharge Size 1-1/2" NPT
Impeller Type 6-Vane
Thermoplastic
Cable Length 10'
Solids Handling 1/4"
Maximum Liquid Temperature 104°F - Intermittent
Acceptable pH Range 6 - 8
Maximum Stator Temperature 120°C
Power Cord Type SJTW
Sensor Cord Type 18/3C
Motor Housing Cast Iron
Casing Cast Iron
Impeller Thermoplastic
Motor Shaft AISI 1045
Hardware SST
O-Rings NBR
Mechanical Seal Single Mechanical
Carbon Ceramic
Upper Bearing 6200
Lower Bearing 6201 - RS
Motor Type PSC
Gen Insulation Class B
Stator Winding Class B
Service Factor 1.00

Dimensions

SPV33 Pump Dimensions

Performance Curve

SPV33 Performance Curve Graph
