Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1 | 1000 V |
---|---|
Rated insulation voltage Ui (pollution degree 3) - UL, CSA | 600 V |
Rated operational frequency - minimum | 25 Hz |
Rated operational frequency - maximum | 400 Hz |
MECHANICAL LIFESPAN AC | 10 million |
MECHANICAL LIFESPAN DC | 12 million |
Electrical lifespan | 1,2 million |
Degree of protection IP (IEC 60529) - Main circuit | IP20 |
Degree of protection IP (IEC 60529) - Control circuit | IP20 |
Rated current In - AC-3 (Ue = 440 V) | 18 A |
---|---|
Rated current In - AC-4 | 8 A |
Rated operational Current Ie AC-1 (¿ = 55 ºC) | 32 A |
Rated operational voltage Ue - IEC 60947-4-1 | 690 V |
Rated operational voltage Ue - UL/CSA | 600 V |
Height | 81 mm (3.19 in) |
Width | 45 mm (1.77 in) |
Depth | 87 mm (3.43 in) |
Gross weight | 300 g |
