Specifications
| Manufacturer | Teco-Westinghouse |
|---|---|
| Catalog Number | SP0/34 |
| Type | BSGS39 |
| Power | 1/3 HP 0.25 kW |
| Speed | 1800 RPM |
| Frame | 48 |
| Voltage | 115/208-230V Single Phase 60Hz |
| Full Load Efficiency | 72.4 % |
| Full Load Power Factor | 81.0 % |
| Full Load Amps | 1.85 Amps @ 230VAC |
| Shipping Weight | 27 lbs |
Features
- Enclosure: Open Drip Proof (IP22)
- Voltage: 115/208/230V (Tri-Voltage)
- Single Phase, 60 Hz
1.15 Service Factor for 115V & 230V
1.0 Service Factor for 208V - Capacitor Start, Capacitor Run
- Class F Insulation
- Automatic Reset Overload
- Class B Temperature Rise
- Designed for 40°C Ambient Temperature
- Designed for 3300 ft. Elevation
- Bi-Directional Rotation
- Rolled Steel Frame
- Cast Aluminum Terminal Box
- 1045 Carbon Steel Shaft
- Aluminum Die Cast Squirrel Cage Rotor Construction
- Paint System: Phenolic Rust Proof Base Plus Lacquer Top Coat
- Paint Color: Blue - Munsell 5 PB 3/8
- Double Shielded Bearings Pre-Packed with Lithium Base Grease
- No Terminals; Lead End Peel-Off Insulation
- Grounding Terminal Inside Main Box
- Stainless Steel Nameplate
- Motors are UL Recognized for United States and Canada
Applications
- Fans
- Pumps
- Compressors
- Air Conditioning Blowers
- Heating
- Ventilation
