Standard Features:
- Manual Reset Protector
- High Efficiency Dual Cap Design
- High Quality Molded Gaskets
- Over 300% Starting Torque
- Cast Iron End Bells
- Dual Oversized Ball Bearings
- Dependable Mechanical Starting Switch
- 18 Month Warranty
Electrical Data:
| Manufacturer | Techtop |
|---|---|
| Part Number | RD1RSTF56C4BC.5 RD1-RS-TF-56C-4-B-C-.5 |
| Horsepower | 1/2 HP |
| Speed | 1725 RPM |
| Voltage | 115/208-230V |
| Phase | Single (1) |
| Full Load Amps | 5.2/2.9-2.6 A |
| Power Factor | 0.90 |
| Nominal Efficiency | 70.0 % |
| Service Factor | 1.15 |
| KVA Code | K |
| LRC @ 60Hz HV | 17.4724 |
| Start Capacitor | SCAP125V-250UF |
| Run Capacitor | RCAP250V-40UF |
| Number of Leads | 7 |
General Data:
| Frame Size | 56C |
|---|---|
| Frame Enclosure | TEFC |
| Mounting | Rigid/C-Flange |
| Insulation Class | F |
| Duty | Continuous / S1 |
| NEMA Design | L |
| Frame Material | Rolled Steel |
| Ingress Protection | IP54 |
| Cable Entry | 0.88” |
| Double Drilled | |
| Paint Color | Graphite Gray |
| Paint RAL | 7024 |
| Weight | 27.0 lbs |
Torque Values:
| Locked Rotor | 5.56092 lb-ft 366.0 % FLT |
|---|---|
| Pull-Up | 4.29984 lb-ft 283.0 % FLT |
| Breakdown | 4.8924 lb-ft 322.0 % FLT |
| Full Load | 1.51938 lb-ft 100.0 % FLT |
