| Model_Number: | S055THH7892011B |
| PRODUCT NAME: | .167 HP - OPDP - 1725 |
| PHASETYPE: | 1_SPLIT PHASE |
| MOTOR ENCLOSURE: | OPDP |
| HORSEPOWER: | .167 |
| KILOWATTS: | 0.1 |
| POLES: | 4 |
| NUMBER SPEEDS: | 1 |
| RPM: | 1725 |
| HERTZ: | 60 |
| VOLTS PRIMARY: | 115 V |
| VOLTS : | 115 |
| FRME : | 48 |
| SHAFT CODE: | YZ |
| STATOR DIAMETER: | 5.5 |
| STACK: | 1 |
| MOUNTING: | BRACKET |
| MOTOR TYPE: | FHP |
| OPPOSITE END BEARING: | BALL |
| SHAFT END BEARING: | BALL |
| AMBIENT: | 50 |
| ROTATION: | CW SHAFT END |
| SERVICE FACTOR: | 1.75 |
| SHIPPING WEIGHT: | 14 |
| THERMAL PROTECTION: | AUTOMATIC RESET |
| BREAKDOWN TORQUE: | 25.73 |
| BREAKDOWN TORQUE UOM: | OZFT |
| LOCKED ROTOR TORQUE: | 22.16 |
| LOCKED ROTOR TORQUE UOM: | OZFT |
| INSULATION CLASS: | B |
| KVA CODE LETTER: | U |
| LOCKED ROTOR AMPS: | 28.49 |
| NEMA NOMINAL EFFICIENCY: | 51.4 |
| FULL LOAD AMPS PRIMARY: | 3.8 |
| SERVICE FACTOR AMPS PRIMARY: | 4.9 |
