Features
Features
- Manual overload protected
- Double sealed ball bearings
- Weather resistant reset button protection
- Capacitor start provides high starting torque
General Specifications
General Specifications
| Model : | M6C17FB167A | Catalog No : | 117865.00 |
| Part Description : | ..1HP..1800RPM.56.TEFC.115/230V.1PH.60HZ.CONT.40C.1.15SF.RIGID......AG-DUTY........ | Category : | Agricultural |
| Stock : | No |
Nameplate Specifications
Nameplate Specifications
| Output HP : | 1 HP | Output KW : | 0.75 kW |
| Frequency : | 60 Hz | Voltage : | 115/208-230 V |
| Current : | 13.4/6.8-6.7 A | Speed : | 1725 RPM |
| Service Factor : | 1.15 | Phase : | 1 |
| Efficiency : | 72 % | Duty : | Continuous |
| Insulation Class : | B | Design Code : | L |
| KVA Code : | J | Frame : | 56 |
| Enclosure : | Totally Enclosed Fan Cooled | Overload Protector : | Manual |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6203 |
| Opp Drive End Bearing Size : | 6203 | UL : | Recognized |
| CSA : | Y | CE : | N |
| IP Code : | 43 |
Technical Specifications
Technical Specifications
| Electrical Type : | Capacitor Start Induction Run | Starting Method : | Across The Line |
| Poles : | 4 | Rotation : | Selective Counterclockwise |
| Mounting : | Rigid base | Motor Orientation : | HORIZONTAL |
| Drive End Bearing : | BALL | Opp Drive End Bearing : | BALL |
| Frame Material : | Rolled Steel | Shaft Type : | T |
| Overall Length : | 12.82 in | Frame Length : | 7.56 in |
| Shaft Diameter : | 0.625 in | Shaft Extension : | 1.88 in |
| Assembly/Box Mounting : | F1 ONLY | UPC : | 691720003664 |
| Weight : | 33.00 LB |
Speed & Load Characteristics
Speed Characteristics
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | Torque (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Pull-Up | 24.40 | 101.00 | 1,250 | 4.20 | 1.00 | |||
| Locked-Rotor | 34.70 | 0.0 | 142.50 | 0.0 | 0 | 7.10 | 85.0 | 1.00 |
| Break-Down | 18.60 | 0.0 | 122.00 | 0.0 | 1,514 | 3.40 | 0.0 | 1.00 |
Load Characteristics
- % of Rated Load
- Current (Amps)
- Rated Output (KW)
- Efficiency (%)
- Power Factor (%)
- Speed (RPM)
- Temp. Rise @ FL
- Torque (ft-lb)
- 0 %
- 4.40
- 0.170
- 0.0
- 16.5
- 1,800
- 0.0
- 0.00
- 25 %
- 4.80
- 0.380
- 50.2
- 34.5
- 1,785
- 0.0
- 11.70
- 50 %
- 5.20
- 0.590
- 64.3
- 49.0
- 1,774
- 0.0
- 23.70
- 75 %
- 5.80
- 0.815
- 70.0
- 60.5
- 1,760
- 0.0
- 35.80
- 100 %
- 6.70
- 1.040
- 72.0
- 69.5
- 1,740
- 75.0
- 48.30
- 115 %
- 7.00
- 1.150
- 74.6
- 72.4
- 1,734
- 95.0
- 55.70
- 125 %
- 7.80
- 1.325
- 71.0
- 73.9
- 1,725
- 0.0
- 61.00
- 150 %
- 9.00
- 1.625
- 69.5
- 78.0
- 1,705
- 0.0
- 74.10
- 175 %
- 10.70
- 1.980
- 66.0
- 80.4
- 1,670
- 0.0
- 88.20
