Features
- Double shielded ball bearings
- Dynamically balanced rotors
- Windings dipped in heavy duty varnish system
- Capacitor start / capacitor run designs to reduce amp draw
- Manual reset overload protection
- High service factor
General Specifications
| Model : | P6K34FK15E | Catalog No : | 114995.00 |
| Part Description : | 2HP..3450RPM.56H.TEFC./V.1PH.60HZ.CONT.MANUAL.40C.1.15SF.RIGID C.PRESSURE WASHER.P6K34FK15E | Category : | Totally Enclosed Fan Cooled (TEFC) |
| Stock : | No |
Nameplate Specifications
| Output HP : | 2 Hp | Output KW : | 1.49 kW |
| Frequency : | 60 Hz | Voltage : | 115/230 V |
| Current : | 17/8.5 A | Speed : | 3450 rpm |
| Service Factor : | 1.15 | Phase : | 1 |
| Efficiency : | 78.5 % | Duty : | CONTINUOUS |
| Insulation Class : | F | Design Code : | L |
| KVA Code : | H | Frame : | 56HC |
| Enclosure : | TEFC | Overload Protector : | MANUAL |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6203 |
| Opp Drive End Bearing Size : | 6203 | UL : | Recognized |
| CSA : | Y | CE : | N |
| IP Code : | 43 |
Technical Specifications
| Electrical Type : | CAP START CAP RUN | Starting Method : | ACROSS THE LINE |
| Poles : | 2 | Rotation : | SELECTIVE CCW |
| Mounting : | RIGID | Motor Orientation : | HORIZONTAL |
| Drive End Bearing : | BALL | Opp Drive End Bearing : | BALL |
| Frame Material : | ROLLED STEEL | Shaft Type : | STANDARD 56 |
| Overall Length : | 12.84 in | Frame Length : | 8 in |
| Shaft Diameter : | 0.63 in | Shaft Extension : | 1.88 in |
| Assembly/Box Mounting : | F1 ONLY | UPC : | 691720014400 |
| Weight : | 45.00 LB |
Speed Characteristics
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | Torque (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Locked-Rotor | 61.00 | 0.0 | 7.20 | 0.0 | 0 | 0.00 | 0.0 | 2.00 |
| Full Load | 8.50 | 0.0 | 3.00 | 0.0 | 3,450 | 0.00 | 0.0 | 2.00 |
| Break-Down | 0.00 | 0.0 | 7.50 | 0.0 | 3,000 | 0.00 | 0.0 | 2.00 |
| Pull-Up | 0.00 | 0.0 | 6.80 | 0.0 | 2,000 | 0.00 | 0.0 | 2.00 |
Load Characteristics
- % of Rated Load
- Current (Amps)
- Rated Output (KW)
- Efficiency (%)
- Power Factor (%)
- Speed (RPM)
- Temp. rise @ FL
- Torque (ft-lb)
- 0 %
- 1.50
- 0.270
- 0.0
- 78.3
- 3,590
- 0.0
- 0.00
- 25 %
- 2.80
- 0.605
- 62.8
- 93.9
- 3,568
- 0.0
- 0.75
- 50 %
- 4.50
- 1.003
- 75.2
- 96.9
- 3,541
- 0.0
- 1.50
- 75 %
- 6.50
- 1.414
- 79.4
- 94.6
- 3,513
- 0.0
- 2.25
- 100 %
- 8.50
- 1.862
- 79.6
- 95.2
- 3,479
- 70.0
- 3.00
- 125 %
- 10.60
- 2.347
- 78.1
- 96.3
- 3,442
- 0.0
- 3.75
- 150 %
- 13.20
- 2.887
- 75.6
- 95.1
- 3,415
- 0.0
- 4.50
