Features
- USDA-approved epoxy painted motors
- Stainless steel Shaft
- NEMA motors
- AC washdown motors
- Rigid base and C face mount types
- BISSC approved designs
- Double lip contact seals and v-ring seals used for shaft seals
- UL recognized and CSA certified
- Single phase motors feature an electronic Solid State Encapsulated switch
General Specifications
| Model : | C6C17WC6G | Catalog No : | 114319.00 |
| Part Description : | ..1 1/2HP. C-FACE LESS BASE- .1725RPM.56.TEFC./V.1PH.60HZ.CONT.40C.1.15SF.ROUND.C6C17WC6G.....WASHGUARD.NOT....... | Category : | General Purpose |
| Stock : | No |
Nameplate Specifications
| Output HP : | 1.50 Hp | Output KW : | 1.1 kW |
| Frequency : | 60 Hz | Voltage : | 115/208-230 V |
| Current : | 19.0/9.5 A | Speed : | 1725 rpm |
| Service Factor : | 1.15 | Phase : | 1 |
| Efficiency : | 71 % | Duty : | Continuous |
| Insulation Class : | F | Design Code : | NO DESIGN CODE |
| KVA Code : | J | Frame : | 56C |
| Enclosure : | Totally Enclosed Fan Cooled | Overload Protector : | No |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6205 |
| Opp Drive End Bearing Size : | 6203 | UL : | Recognized |
| CSA : | Y | CE : | N |
| IP Code : | 55 |
Technical Specifications
| Electrical Type : | Capacitor Start Induction Run | Starting Method : | Across The Line |
| Poles : | 4 | Rotation : | Selective Counterclockwise |
| Mounting : | Round | Motor Orientation : | HORIZONTAL |
| Drive End Bearing : | BALL | Opp Drive End Bearing : | BALL |
| Frame Material : | Rolled Steel | Shaft Type : | NEMA 56 |
| Overall Length : | 13.37 in | Frame Length : | 7.50 in |
| Shaft Diameter : | 0.625 in | Shaft Extension : | 1.88 in |
| Assembly/Box Mounting : | F1 ONLY | UPC : | 691720013892 |
| Weight : | 46.00 LB |
Speed Characteristics
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | Torque (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Break-Down | 31.72 | 318.0 | 150.00 | 278.0 | 1,500 | 6.32 | 0.0 | 1.50 |
| Pull-Up | 42.05 | 422.0 | 81.00 | 150.0 | 1,175 | 7.01 | 0.0 | 1.50 |
| Locked-Rotor | 50.95 | 512.0 | 150.00 | 278.0 | 0 | 9.76 | 0.0 | 1.50 |
| Full Load | 9.96 | 100.0 | 54.00 | 100.0 | 1,749 | 1.62 | 0.0 | 1.50 |
Load Characteristics
- % of Rated Load
- Current (Amps)
- Rated Output (KW)
- Efficiency (%)
- Power Factor (%)
- Speed (RPM)
- Temp. rise @ FL
- Torque (ft-lb)
- 0 %
- 6.29
- 0.274
- 0.0
- 18.9
- 1,795
- 0.0
- 0.00
- 25 %
- 6.55
- 0.583
- 48.9
- 38.7
- 1,783
- 0.0
- 18.00
- 50 %
- 7.35
- 0.903
- 62.7
- 53.4
- 1,771
- 0.0
- 36.00
- 75 %
- 8.40
- 1.231
- 68.5
- 63.7
- 1,759
- 0.0
- 54.00
- 100 %
- 9.72
- 1.583
- 70.4
- 70.8
- 1,743
- 105.0
- 72.00
- 125 %
- 11.35
- 1.975
- 69.9
- 75.6
- 1,726
- 0.0
- 90.00
- 150 %
- 13.34
- 2.427
- 67.3
- 79.0
- 1,704
- 0.0
- 108.00
