Features
Features
- Rugged die cast aluminum gear housing for maximum gear and bearing support
- Precision machined gearing, hardened for maximum load capability
- All gearing designed and rated to AGMA class 9 standards, and to withstand momentary shock overload of 200%
- Oversized output bearings for greater overhung load capacity and long life
- High carbon alloy output shaft provides maximum strength and rigidity
- All needle bearing journals are precision ground after heat treating to provide maximum fit and finish
- Heavy duty industrial oil seals keep lubricant in and dirt out
- Gears and bearings are splash lubricated with permanent, heavy duty gear oil
- Conduit box included as standard
General Specifications
General Specifications
| Model : | C4D17FZ25C | Catalog No : | 108709.00 |
| Part Description : | ..1/2HP..42RPM.P1102-48.TEFC.90V..DC.....C4D17FZ25C.P1100...42:1.DC GEARMOTORS FHP..705LBIN..DOUBLE.... | Category : | P1100 Series |
| Stock : | No |
Nameplate Specifications
Nameplate Specifications
| Output HP : | 0.50 Hp | Output KW : | 0.37 kW |
| Voltage : | 90 V | Current : | 5.0 A |
| Speed : | 42 rpm | Service Factor : | 1 |
| Efficiency : | 72.2 % | Duty : | Continuous |
| Insulation Class : | F | Frame : | 48Y |
| Enclosure : | Totally Enclosed Fan Cooled | Overload Protector : | No |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6203 |
| Opp Drive End Bearing Size : | 6203 | UL : | Recognized |
| CSA : | Y | CE : | N |
Technical Specifications
Speed Characteristics
Technical Specifications
| Rotation : | Reversible | Mounting : | Special |
| Shaft Type : | Parallel | Overall Length : | 16.31 in |
| Frame Length : | 5.97 in | Shaft Diameter : | 0.750 in |
| Shaft Extension : | 1.5 in | UPC : | 691720007143 |
| Weight : | 40.00 LB |
