Features
Features
- Double shielded ball bearings
- Designed for belted loads
- High starting and breakdown torque
- Dual rotation
General Specifications
General Specifications
| Model : | C184K34DB8A | Catalog No : | 132044.00 |
| Part Description : | ..7 1/2HP..3450RPM.184.DP./208-230V.1PH.60HZ.CONT.40C.1.15SF.RIGID.C184K34DB8A.....AIR COMPRESSOR.AUTOMATIC....... | Category : | Air Compressor |
| Stock : | No |
Nameplate Specifications
Nameplate Specifications
| Output HP : | 7.50 Hp | Output KW : | 5.6 kW |
| Frequency : | 60 Hz | Voltage : | 208-230 V |
| Current : | 34.0-31.0 A | Speed : | 3450 rpm |
| Service Factor : | 1.15 | Phase : | 1 |
| Efficiency : | 82.5 % | Duty : | Continuous |
| Insulation Class : | F | Design Code : | L |
| KVA Code : | H | Frame : | 184T |
| Enclosure : | Drip Proof | Overload Protector : | Automatic |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6206 |
| Opp Drive End Bearing Size : | 6205 | UL : | Recognized |
| CSA : | Y | CE : | N |
| IP Code : | 22 |
Technical Specifications
Technical Specifications
| Electrical Type : | Capacitor Start Capacitor Run | Starting Method : | Across The Line |
| Poles : | 2 | Rotation : | Selective Counterclockwise |
| Mounting : | Rigid base | Motor Orientation : | HORIZONTAL |
| Drive End Bearing : | BALL | Opp Drive End Bearing : | BALL |
| Frame Material : | Rolled Steel | Shaft Type : | T |
| Overall Length : | 16.69 in | Frame Length : | 12.50 in |
| Shaft Diameter : | 1.125 in | Shaft Extension : | 2.75 in |
| Assembly/Box Mounting : | F1 ONLY | UPC : | 691720346518 |
| Weight : | 110.00 LB |
