Features
- USDA-approved epoxy painted motors
- NEMA motors
- AC washdown
- Rigid base and C face mount types
- BISSC approved designs; Double lip contact seals and v-ring seals used for shaft seals
- 3-year warranty on encapsulated and premium efficient models
- UL recognized and CSA certified
- Washdown brakemotors and pump motors available
General Specifications
| Model : | C6T17WC24C | Catalog No : | 116644.00 |
| Part Description : | ..1/2HP..1725RPM.56.TEFC.208-230/460V.3PH.60HZ.CONT.40C.1.15SF.ROUND.C6T17WC24C.....WASHGUARD.NOT....... | Category : | General Purpose |
| Stock : | No |
Nameplate Specifications
| Output HP : | 0.50 Hp | Output KW : | 0.37 kW |
| Frequency : | 60 Hz | Voltage : | 208-230/460 V |
| Current : | 2.0/1.0 A | Speed : | 1725 rpm |
| Service Factor : | 1.15 | Phase : | 3 |
| Efficiency : | 74 % | Duty : | Continuous |
| Insulation Class : | F | Design Code : | B |
| KVA Code : | K | Frame : | 56C |
| Enclosure : | Totally Enclosed Fan Cooled | Overload Protector : | No |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6205 |
| Opp Drive End Bearing Size : | 6203 | UL : | Recognized |
| CSA : | Y | CE : | Y |
| IP Code : | 55 |
Technical Specifications
| Electrical Type : | Squirrel Cage Induction Run | Starting Method : | Across The Line |
| Poles : | 4 | Rotation : | Reversible |
| Mounting : | Round | Motor Orientation : | HORIZONTAL |
| Drive End Bearing : | BALL | Opp Drive End Bearing : | BALL |
| Frame Material : | Rolled Steel | Shaft Type : | NEMA 56 |
| Overall Length : | 10.87 in | Frame Length : | 5.00 in |
| Shaft Diameter : | 0.625 in | Shaft Extension : | 1.88 in |
| Assembly/Box Mounting : | F1 ONLY | UPC : | 691720343487 |
| Weight : | 23.00 LB |
Speed Characteristics
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | Torque (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Full Load | 2.00 | 24.00 | 100.0 | 0 | 0.50 | |||
| Pull-Up | 0.00 | 59.00 | 246.0 | 0 | 0.50 | |||
| Break-Down | 0.00 | 86.50 | 360.0 | 0 | 0.50 | |||
| Locked-Rotor | 10.20 | 60.00 | 250.0 | 0 | 0.50 |
Load Characteristics
- % of Rated Load
- Current (Amps)
- Rated Output (KW)
- Efficiency (%)
- Power Factor (%)
- Speed (RPM)
- Temp. rise @ FL
- Torque (ft-lb)
- 0 %
- 0.85
- 0.107
- 0.0
- 27.9
- 1,793
- 0.0
- 0.00
- 25 %
- 0.85
- 0.209
- 45.0
- 30.5
- 1,786
- 0.0
- 6.10
- 50 %
- 0.90
- 0.311
- 60.5
- 43.5
- 1,773
- 0.0
- 11.90
- 75 %
- 0.95
- 0.415
- 67.5
- 54.5
- 1,758
- 0.0
- 18.00
- 100 %
- 1.05
- 0.568
- 70.0
- 63.0
- 1,743
- 57.0
- 23.90
- 125 %
- 1.15
- 0.656
- 72.0
- 72.0
- 1,724
- 0.0
- 30.00
- 150 %
- 1.30
- 0.778
- 69.0
- 72.0
- 1,705
- 0.0
- 35.50
