Features
- Standard efficient ratings
- Inverter-rated; Continuous duty
- Class B insulation systems – 42, 48 and 56 frames
- UL recognized and CSA certified
- Shielded ball bearings for direct coupled applications Contact your local sales office for belted load applications
- Dynamically balanced rotors
- Torques exceed NEMA performance standards
General Specifications
| UPC: | 691720000700 | Weight: | 15.00 LB |
| Packaged Length: | 14.44 IN | Packaged Width: | 7.94 IN |
| Packaged Height: | 10.88 IN |
Nameplate Specifications
| Output HP: | 0.17 Hp | Output KW: | 0.13 kW |
| Frequency: | 60 Hz | Voltage: | 208-230/460 V |
| Current: | 0.88/0.44 A | Speed: | 1725 rpm |
| Service Factor: | 1 | Phase: | 3 |
| Efficiency: | 66 % | Power Factor: | 54 |
| Duty: | Continuous | Insulation Class: | B |
| Design Code: | No Design Code | KVA Code: | M |
| Frame: | 42 | Enclosure: | Totally Enclosed Non Ventilated |
| Thermal Protection: | No | Ambient Temperature: | 40 °C |
| Drive End Bearing Size: | 6203 | Opp Drive End Bearing Size: | 6203 |
| UL: | Recognized | CSA: | Y |
| CE: | N | IP Code: | 43 |
Technical Specifications
| Electrical Type: | Squirrel Cage Induction Run | Starting Method: | Across The Line |
| Poles: | 4 | Rotation: | Reversible |
| Resistance Main: | 100 Ohms | Mounting: | Rigid Base |
| Motor Orientation: | Horizontal | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | Single Special Extension | Overall Length: | 7.56 in |
| Frame Length: | 4.75 in | Shaft Diameter: | 0.375 in |
| Shaft Extension: | 1.12 in | Assembly/Box Mounting: | F1 Only |
Speed & Load Characteristics
